HEX11WP-TX-US

• Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
• Supports 4K UHD video up to 40m (3840 x 2160 @ 30Hz 4:4:4, 4096 x 2160 @ 24Hz 4:4:4, and 4K @ 60Hz 4:2:0)
• Extends HDMI at 1080p up to a distance of 70m
• Smart EDID function automatically limits EDID to within HDBaseT™ specification to improve compatibility
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• Supports 12V-48V PoC from compatible Blustream HDBaseT™ receiver / matrix products
• Bi-directional RS-232 pass-through
• Supports IR pass-through to HDBaseT™ device
• Compatible with all Blustream HDBaseT™ receiver / matrix products*
• Magnetic faceplate surround and US Decora style backbox compatibility
• HDCP 2.2 support

*Technical performance is subject to the features supported on the connected HDBaseT™ device

• Video Input Connectors: 1 x HDMI Type A, 19-pin, female
• Video Output Connectors: 1 x HDBaseT™ RJ45 connector
• RS-232 Serial Port: 1 x 3-pin Phoenix connector
• IR Input Port: 1 x 3-pin Phoenix connector
• Local Power Input: 1 x 2-pin Phoenix connector
• Module Dimensions (W x H x D): 89mm x 105mm x 44mm (w/o faceplate)
• Faceplate Dimensions (W x H x D): 115mm x 115mm x 6mm
• Cut Out Dimensions (W x H x D): 89mm x 70mm x 37mm
• Mounting Hole Spacing: US 97mm CTC
• Backbox Requirements: US double gang junction box
• Shipping Weight: 1.0Kg
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Power Supply: 12V/1A DC

1 x HEX11WP-TX-US
1 x 12V/1A DC Power Supply
1 x Magnetic Faceplate
1 x Quick Reference Guide
